Power through the most complex, demanding applications more quickly with a new generation of dual-socket performance with the Intel Xeon Scalable Processor family featuring up to 56 cores with dual processor. Top-of-the-line power to fuel those who reimagine our world. our workstation capable to run complex simulations, handle advanced Machine Learning algorithms and process huge amounts of data.
| Feature | CYNIX ProX ix8440 Workstation Technical Specifications |
| Processor | Up to two 205W Gen 1 or Gen 2 Intel® Xeon® Scalable family processors, Bronze, Silver, Gold, or Platinum |
| Chipset | Intel C6xx Series Chipset |
| Operating System Options | Windows 11 Pro for Workstations
Windows 10 Pro for Workstations Ubuntu 20.04LTS Red Hat® Enterprise Linux® |
| Video Card | Entry 3D:
NVIDIA® T400 (4GB GDDR6 dedicated) NVIDIA® T400 (2GB GDDR6 dedicated) NVIDIA® Quadro® P620 (2GB GDDR5 dedicated)
Mid-range 3D: NVIDIA® T1000 (8GB GDDR6 dedicated) NVIDIA® T1000E (8GB GDDR6 dedicated) AMD Radeon™ Pro WX3200 (4GB GDDR5 dedicated) NVIDIA® Quadro® P1000(4GB GDDR5 dedicated) NVIDIA® Quadro® T1000 (4GBG DDR6 dedicated) NVIDIARTX™️ A2000 (6GB GDDR6 dedicated)
High-end 3D: NVIDIA RTX™️ A4500 (20GB GDDR6 dedicated) NVIDIA RTX™️ A4000 (16GB GDDR6 dedicated) AMD Radeon™ Pro W5500 (8GB GDDR5 dedicated); AMD Radeon™ Pro W5700 (8GB GDDR5 dedicated)
Ultra High-end 3D: NVIDIA® Quadro® GV100 (32GB GDDR5 dedicated) AMD Radeon™ Pro W6800(32GB GDDR6 dedicated) NVIDIA® RTX™A6000 (48GB GDDR6 dedicated) NVIDIA® RTX™A5000 (24GB GDDR6 dedicated) NVIDIA® Quadro® SYNC II |
| Memory | 3TB DDR4-2666ECC SDRAM; 1.5TB DDR4-2933ECC SDRAM Transfer rates up to 2933MT/s |
| Memory slots | 24 DIMM with 2 processors |
| Communication | Integrated: Intel® Gigabit Ethernet controllers with Intel Remote Wake UP
Optional: Intel® i210 10/100/1000 single port PCIe (Gen 3 x1) gigabit network card, Intel® X550-T2 10GbE dual port PCIe (Gen 3 x4) network card, Intel Dual Band Wireless AC 8265 (802.11ac) 2×2 + Bluetooth module,
|
| Ports | Front:
1 headset connector 4 USB 3.1
Rear: 6 USB3.1 Gen 1 2 RJ-45 (1GbE) 1 audio-in; 1 audio-out 1 PS/2mouse port 1 PS/2keyboard port 1 serial (optional) |
| Optical Drive | Slim DVD-ROM
Slim Blu-ray Writer Slim DVD-Write |
| Form factor | Micro Tower |
| Drive Bays | Two 5.25″, Four 2.5″ or 3.5 |
| Slots | All slots PCIe Gen 3:
(2) PCIe x16, (2) additional x16 slots with 2nd CPU; (1) PCIe x8 open ended, (1) x16 wired as x 4, (1) x16 wired as x1 |
| Primary Storage | 3.5″” SATA HDD 6Gb/s 7.2k RPM up to 12TB
2.5″” SAS HDD 12GB/s 10k RPMup to 600GB 2.5″” SATA SSD 6GB/s up to 2TB 2.5″” U.2 PCIe NVMe SSD up to 1.5TB M.2 PCIe NVMe SSD up to 2TB |
| Storage Controller | M.2 SSD Controllers
Integrated NVMe Controller with RAID 0/1/10 Upgrade Integrated NVMe Controller, non-RAID HDD Controllers Onboard Intel RSTe SATA |
| Warranty | 3 Years Hardware Service with Onsite/In-Home Service after Remote Diagnosis, warranty extensions up to 5 years
Accidental Damage Service is available to accompaniment certain warranty options from 3-5 years Keep your hard drive Options Available on certain SKU. |
| Audio and Speakers | Integrated high-definition audio controller
Optional Internal Speaker |
| Power | Standard Internal power supply, up to 90% efficiency, active PFC; |
| Hardware Security | Kensington security-cable slot (Optional)
Padlock loop (Optional) Chassis intrusion switch (Optional) |
| Input devices | CYNiX Wired Keyboard Black (English) – US International
CYNiX Wired Mouse Black Wireless Keyboard and Mouse (Optional) |
| Environmental | Operating temperature: 5 to 35°C;
Operating humidity: 5 to 90% RH |
